Semi automatic pre stretch film rewinding machine

Semi automatic pre stretch film rewinding machine

  • PPD-SPRE600

  • Semi automatic pre stretch film rewinding machine is designed for rewinding the stretch film jumbo roll to product pre stretch film small roll or standard stretch film product roll.
    As multifunctional option,this machine can work as a standard pre stretch film slitter rewinder by using the knife system.

    Features:

    1:The pre stretch ratio can be 100%-300% adjustable by buyer requirement.

    2:Machine is simple,operate easily.

    3:Machine is with automatic meter counter.

    Machine data:

    Machine name:Semi automatic pre stretch film rewinding machine

    Machine model:PPD-SPRE600

    Max mother roll width:500mm

    Max mother roll diameter:400mm

    Mother roll inner diameter:76mm(3inch)

    Material loading:Pneumatic cylinder

    Product roll inner diameter:1.5/2/3inch (option)

    Max product roll diameter:300mm

    Product roll width:500mm

    Max rewinding speed:600rpm/min

    Voltage:220/380/415/450v,3ph(option)

    Weight:750kg

    NOTE:ANY SPECIFICATIONS CAN BE CUSTOMIZED.
