PPD-HSR500

Hand Stretch Film Roll Winder

Hand Stretch Film Roll Winder

Hand stretch film roll winder is ideal for rewind the jumbo roll of LDPE of stretch film into smaller diameter hand roll.manual stretch wrap roll.
Machine is very fast for opertion,high speed production for semi automatic standard.very simple in operation.
The non-skilled operator can run the machine,it is compact in size,competitive in price,very ideal for low investment purpose to stretch film converting beginning.

Technical Specs:

Name:Hand Stretch Film Roll Winder

Model:PPD-HSR500

Material:LDPE stretch film

Max width of master roll:500mm

Max outer dia of master roll:400mm

Inner chuck of master roll:76mm

Sub roll total width:500mm

Sub roll inner chuck:38/50/76mm

Sub roll outer dia:160mm max

Speed:0-300m/min

Total power supply:1.5kw

Pneumatic supply:0.3-0.4Mpa
