Food wrapping film rewinding machine

PPD-PP450

2 Shaft Parchments Paper Rewinder

2 shaft parchments paper rewinder is our latest model of 2 turret food paper rewinder. It is mainly used to rewinding of silicon paper, wax paper, baking paper, PE coated paper,bakery paper and parchment paper etc.
Machine adopts PLC control, touch screen operation, and frequency converter control system, which greatly improves the production efficiency.

Features:
1.Machine use silicon roller replaces the traditional roller, which make the rewinding more smooth and not easy to wrinkle.
2. Air shaft and magnetic powder tension control to realize the synchronization between the rollers, and make the unwinding and rewinding more stable.
3. Automatic meter counting,automatic exchange,automatic cutting, high degree in automation.

Main data:

Name:2 Shaft Parchments Paper Rewinder

Model:PPD-PP450

Unwind roll width:max450

Unwind roll core diameter:3inch

Unwind roll OD:600mm max

rewind roll width:max 450mm

rewind roll core diameter:35/38/40mm

rewind roll length setting:2-300meter

Speed:300rpm/min max

Total power: 2.2kw

NOTE: Different sizes can be customized.
