PPD Machinery

PPD-BPRL450

Baking Paper PE Coated Paper Wax Paper Rewinder With Auto Label Sticker

Baking Paper PE Coated Paper Wax Paper Rewinder With Auto Label Sticker

Baking Paper PE Coated Paper Wax Paper Rewinder With Auto Label Sticker

Baking paper PE coated paper wax paper rewinder with auto label sticker is a multifunctional rewinding machine that integrates rewinding and automatic labelling attachment.
Machine is mainly used for rewinding of silicon paper, baking paper, PE coated paper, bakery paper, wax paper etc. Machine can also rewind aluminum foil roll products, which are widely used in food, packaging, medical industry and so on.

Features:
1. The machine is stable in performance, easy operation and high efficiency.
2. Automatic feeding, automatic rewinding, automatic paper core changing, automatic gluing, high degree of automation.
3. The air shaft fixes the jumbo roll to prevent the jumbo roll from running off.
4. Frequency conversion speed regulation, speed is displayed on the control panel.
5. Automatic meter counting device, the length can be set and displayed on the PLC control panel directly.

 Technical Parameters:

Name:Baking Paper PE Coated Paper Wax Paper Rewinder With Auto Label Sticker
Model: PPD-BPRL450
Mother roll width: max450mm
Material thickness: 0.008-0.05mm
Diameter of mother roll paper tube: 3”
Outer diameter of parent roll:max 800mm
Rewinding width: max450mm
Rewinding length: max150m
Inner diameter of winding paper tube: 25/35/38mm or as customized
Rewinding speed: max 2m/s
Roll change method: automatic roll change
Voltage: 380V, 3ph


Get Quote: Baking Paper PE Coated Paper Wax Paper Rewinder With Auto Label Sticker-PPD-BPRL450
