Auto cling film rewinding machine

Book cover roll rewinder adopts programmable controller, rotation and button mode to set parameters, and the stepping motor has fixed length traction.
The machine has the functions of automatic feeding, automatic cutting, and automatic inflation and deflation of the inflatable shaft
It is an essential machine for the production of book cover, wallpaper, and gift paper etc .
With high precision of fixed length, neat winding, easy operation, beautiful appearance, stable in performance,it can also form a production line with automatic shrink packaging machine.

Features：
1.Machine adopts servo motor to control the feeding. The PLC touch screen automatically counts the meter, automatically cuts off.
2.Unwinding with a 3-inch air-up shaft，the maximum unwinding diameter: Φ1200mm
3.It can be exchanged for a variety of specifications, gas rise shaft rewinding, (according to customer needs)
3. The winding tension mode is automatic tension magnetic powder control.
4.Can do both coreless roll and roll with paper core

Main Data：
