Auto stretch film rewinding machine

PPD-ARW500

Food Grade Fully Automatic Stretch Wrap Film Rewinder

Food grade fully automatic stretch wrap film rewinder is a highly automated industrial equipment, specially used to rewind large and wide rolls of wrap film into small rolls or rolls of specific specifications that meet the user's specific requirements (such as width, length, roll diameter, and inner diameter of the roll core). The machine body is made of stainless steel and realizes a fully automatic operation process to minimize manual intervention.

Features:
1. Main frame: The frame is made of stainless steel to ensure high rigidity, corrosion resistance, and easy cleaning.
2. Finished roll conveyor line: Receive the finished small rolls that are automatically unloaded and convey them to the receiving table for easy packaging.
3. PLC programmable logic controller machine, HMI (human-machine interface touch screen), convenient parameter setting, and can monitor the operating status (rewinding length, speed, etc.) at any time.

Main Data:

Name: Food Grade Fully Automatic Stretch Wrap Film Rewinder

Model: PPD-ARW500

Width of parent roll:500mm

Inner diameter of parent roll:76mm

Outer diameter of parent roll:500mm

Rewinding width:max500mm

Rewinding inner diameter:38/50/76mm

Rewinding outer diameter:max180mm

Speed:max1200m/min

Total power:4.37kw

Air supply: 0.3Mpa
