PPD Machinery

PPD-SAPR600

Pre Stretch Film Rewinder

Pre Stretch Film Rewinder

By speed ratio pre-stretching of roller guiding,it can rewind the jumbo roll can be to hand rolls. According to the difference of the speed ratio, it can result difference
pre-stretching need,this is a way to make the stretch film more economical for longer total length.with pre stretched film,the surface looks more smooth.
It can pre stretch the film to 100% to 300% for the total length from the unwind mother roll.
Mean time,it can work as a pre stretch film slitter to slit the mother roll into a few of pre stretched hand rolls,further more,it can act as stretch film slitter,and a stretch film rewinder machine if not go under the pre stretched rollers.
In option,it can work as a coreless stretch film slitter or rewinder if buyer request to add the pneumatic cylinder.It is now very popular in world market to r
This model is semi automatic user friendly,cost effective.less skilled operator request,less daily maintainence requested.

Technical Data:

Name:Pre Stretch Film Rewinder

Model:PPD-SAPR600

Max mother roll width: 600mm

Mother roll core:3inch

Finished roll core:1.5/2/3inch

Finished roll max outer diameter:180mm

Speed:max600mm/min

Voltage:380V,3 phase or 220v
