Auto stretch film rewinding machine
PPD-4ASH500
Automatic Rewinding Machine For Stretch Film
Automatic rewinding machine for stretch film is the new designed model for rewinding of the the big diameter rolls into small diameter rolls of PE stretch film rolls,industrial rolls,hand rolls,machine rolls,HDPE film,LLDPE film and cling film rolls etc.
Machine works with high speed 4 shafts rewinding system,automatic change the paper core to improves the production more than 50% than the market conventional modelcan reduce the production cost.
The design speed of this model is at 1200m/min.
It is control by PLC programme,operate by touch screen,user friendly.
Main data:
Machine name: Fully auto 4 shaft stretch wrap film rewinder
Model:PPD-4ASH500
Unwind roll width:max500mm or as customized
Unwind roll diameter:max500mm
Unwind roll inner diameter:76mm
Rewind roll inner diameter:50mm,76mm option
Prodution speed:1200m/min
Voltage:220/380/415/450v,3ph(option)
Power:5kw
NOTE:Different sizes can be customized.
