PPD-HARW500

High Speed CE Cover Stretch Wrap Film Winding Machine

High Speed CE Cover Stretch Wrap Film Winding Machine

High speed CE cover stretch wrap film winding machine is the latest model for stretch wrap film rewinding.
All the specifications of this model have been increased than before.
All the bearing of this machine use top brand.
The thickness of machine wall frame is increased,machine will be more strong and run stabley.

Main Technicial Data:

Name: High speed CE cover stretch wrap film winding machine

Model:PPD-HARW500

Parent roll width :max500mm

Parent roll OD :500mm

Parent roll core size :3inch

Sub roll width:max500mm

Sub roll diameter:max200mm

Sub roll core size:1.5/2/3inch

Machine design speed:1500m/min

Voltage:220/380/415/450V

Power:4.37kw

NOTE:Different sizes can be customized.


NOTE:

The standard rewinding diameter is at 160mm

If you want to make the jumbo roll at 250-300mm,it is specific customized model,please inform us before you order.
