Coreless pe coated food paper rewinder

PPD-CBP450

Coreless Baking Paper Silicon Paper Rewinding Machine

Coreless baking paper silicon paper rewinding machine is mainly designed to rewind silicon paper, baking paper, wax paper, PE coated paper, steamer paper, book cover etc.
The final product roll is without paper core,can save the cost of paper core.
Machine works with 6 rewind shaft for fast exchange the next shaft once finished rewind,automatic cutting,once reach the setting length,very easy to operate.
Unwinding roll adopts air shaft loading and magnetic powder tension control to make the machine run more stablely.

.

Main technical data:

Name：Coreless Baking Paper Silicon Paper Rewinding Machine

Model：PPD-CBP450

Raw material width:max 450mm

Raw material inner core diameter:76mm

Raw material OD:600mm max

Finished roll width:same to raw material

Finished roll inner core diameter:25mm

Finished roll length:2-60mtrs

Total power:2.5kw

Speed:max 600rpm/min

Voltage:220/380/415/450v option
