PPD-45T/63T

Fully Automatic Aluminium Foil Container Making Machine

Fully Automatic Aluminium Foil Container Making Machine

Fully Automatic Aluminium Foil Container Making Machine adopts imported Seimens motor,PLC and Schneider electronic componets to make sure the machine's top quality, the whole line include automatic feeding machine,press machine,mould,automatic stacker and scrap presser.

Production:
Auto feeding -- control panel -- length controller-- 45T/63T pneumatic press --mould-- full-automatic stacker—Scrap Presser

 Technical data:



ITEM

PPD-45T

PPD-63T

Strokes

40-75times/min

30-70times/min

Motor Capacity

6.5KW

8KW

Voltage

3-380V 50HZ

4wires

3-380V 50HZ

4wires

Total Weight

6500KGS

(approximate)

7500KGS

(approximate)

Area

7mx3m

7mx3m

Press Dimension

1620x1050x2960

1820x1250x3080

Core Coil Head Dia

3min/6inch

3min/6inch

Max. Foil Roll Outer Dia

700mm

800mm

Max. Foil Width

550mm

670mm



Auto feeding part:







Pneumatic press:







Mould:









Auto stacker:
