Aluminium foil food paper rewinder

New Model automatic aluminum foil rewinding machine is widely used for rewinding of aluminiumcatering foil roll,household foil roll,kitchen foil roll, household foil roll,and other aluminium foil roll products.
Machine is with 4 shaft automatic exchange,automatic gluing,automatic rewinding,automatic stop when reach the setting length,automatic cut off,automatic deliver to packing area.
With PLC man-machine interface communication, touch screen operation,it is very user friendly model.
New model automatic aluminum foil rewinding machine adopts steel rollers conveyor products instead of belts conveyor,make the product roll more beautiful.

Features:
1.Machine structure is simple, easy to operate, easy maintenance.
2.Applicable to aluminum foil roll and food paper rewinding
3.Depending on the width, the machine can be properly adjusted.
4.Through rewinding, you can produce different length of the product.
5.Machine is no noise, low energy consumption, advanced structure.
6.Electrical appliances imported brands, product stability and good performance, high precision operation.
7.Touch screen operation,PLC control.

Technical Data:

Name:New Model Automatic Aluminum Foil Rewinding Machine

Model:PPD-NAAF450

Raw materials width:Max450mm

Unwind roll diameter:max800mm diameter

Raw material mother roll core ID:76mm (core ID)

Finished Roll Rewinding Core ID:35mm,38mm(optional)

Slitting length finished roll control:3 to 150M

Speed:max150m/min

Unloading magnetic power brake:25N.M

Winding magnetic power clutch:12N.M

Electrical Power & Supply:4Kw

Voltage:380V,3Ph,50Hz
