Coreless pe coated food paper rewinder

PPD-PFCSR500(4 IN 1)

Semi Automatic Silicon Paper Aluminium Foil Cling Film Stretch Film Rewinder (4 in 1)

Semi automatic Silicon paper aluminium foil cling film stretch film rewinder is 4 in 1
model,by the material individual features,machine is buit with the two different
unwind roll station for both baking paper, aluminum foil, cling film and stretch film jumbo roll.
This model is controlled by LCD touch screen monitoring device,PLC
human-machine interface communication programable logic controller,very user
friendly,non-skilled person can operate the machine.

Features:
1.The machine body adopts steel plate and casting structure
2.Machine adopts two-station winding. After the number of meters is reached, it will automatically stop and cut.
3.Rewinding specifications: Width:120-500mm option, maximum outer
diameter:120mm
4.Paper core clamping method: shaftless chucks, pneumatic
5.Tension control: surface rewinding is controlled by tension.

Main Data:

Name:Semi Automatic Silicon Paper Aluminium Foil Cling Film Stretch Film Rewinder(4 in 1)

Model:PPD-PFCSR500(4 IN 1)

Rewind material：aluminium foil /silicon paper/cling film / stretch film

Jumbo roll core diameter:76mm

Jumbo roll width:max500mm

Jumbo roll weight:max 200kg

Rewind roll width:max500mm

Rewind roll paper core ID:30/35/38/40/50/76mm option

Rewind roll diameter:max120mm

Rewind roll length:max500m

Design speed:0-600m/min adjustable
